Type: CTA-1000
    CTA-1000 Series CT Analyzer automatically determines all relevant current transformer values and compares the results with the selected standard. The device evaluates the current transformer as per the IEC or IEEE standard within seconds with the push of a button.
    It facilitates fast and economical on-site testing and calibration of metering and protection current transformers. Manufacturers of current transformers, high voltage transformers and switchgear also use the CT Analyzer for tests during development and production.
Online Service
Product Features
    1. Wide range of measurements:
    (1) CT:
    • CT ratio and phase-angle accuracy
    • CT accuracy for different burdens
    • CT winding resistance
    • CT excitation characteristics
    • CT inductance (saturated and unsaturated)
    • ALF and FS (direct and indirect)
    • Burden impedance
    • CT residual magnetism
    (2) PT:
    • PT excitation and saturation
    • Burden impedance
    • Winding resistance Saturated and non-saturated inductance
    • PT polarity
    2. Easy to use. The CT PT Analyzer allows all types of single and multi-ratio current transformers to be tested, and it evaluates the current transformer within seconds with the push of a button;
    3. Highest measurement accuracy: 0.05% / 2 min when calibrating on site;
    4. Automatic evaluation according to IEC and IEEE standards;
    5. Short commissioning times (duration of the automatic test<2min);
    6. Excellent workplace safety - Tests run at max. 180V;
    7. Very small and lightweight (<9kg/19.8lbs), easy to transport for on-site testing;
    8. Professional pull box design, easy to carry, anti-vibration.
Applications
    The following values can be determined using the CT/PT Analyzer:
    1. CT:
    (1) Accuracy of the ratio and phase angle, taking into consideration the nominal burden and connected burden
    (2) CT excitation and saturation
    (3) Burden impedance
    (4) Winding resistance Saturated and non-saturated inductance
    (5) CT polarity
    2. PT:
    (1) PT excitation and saturation
    (2) Burden impedance
    (3) Winding resistance Saturated and non-saturated inductance
    (4) PT polarity
Technical Parameter
Type CTA-1000C
Usage CT,PT
Output 0~180Vrms,12Arms,36A(peak value)
Voltage measurement accuracy ±0.1%
CT Ratio Range 1~40000
accuracy ±0.05%
PT Ratio Range 1~40000
accuracy ±0.05%
Phase Range ±2min
accuracy 0.5min
DC resistance Range 0~300Ω
accuracy 0.2%±2mΩ
Burden Range 0~1000VA
accuracy 0.2%±0.02VA
Power supply AC220V±10%,50Hz
Environmental Conditions Operating temperature: -10℃~50℃
Humidity:≤90%
Weight and Dimensions Dimensions:365mm×290mm×153mm
Weight:≈10kg
Standard Accessories
No. Name Type Unit Quantity
1     Host     CTA-1000C set 1
2     Up-flow reactor(optional)     CTP-180A set 1
3     Power line     250V/16A/1.5m set 1
4     Red test line     2.5mm 2*6m pcs 1
5     Yellow test line     2.5mm 2*6m pcs 1
6     Green test line     2.5mm 2*6m pcs 1
7     High current test line(optional)     25mm 2*6m a red & a black pcs 2
8     Control line(optional)     Special purpose control line for elevator pcs 1
9     Ground wire     2.5mm 2*3m pcs 1
10     Alligator clip     Opening 12mm, a yellow& a green,two black pcs 4
11     Alligator clip     Opening 20mm, a red, a black pcs 2
12     U type insert     Opening 6mm, two red and two black pcs 4
13     Thermal printing paper       volume 4
14     U disk     8G pcs 1
15     Protective tube     10A pcs 5
16     Special screwdriver for protective tube     6*38mm pcs 1
17     Quality testing report       copy 1
18     Instruction manual       copy 1
19     Aluminum alloy packing box       pcs 1
