Transformer Ratio Tester

The ZC-203B-ii multifunctional variable ratio tester is a new generation intelligent product independently developed by our company. The instrument uses an ARM processor and is easy to operate. The instrument has exquisite circuit design, superior performance, powerful functions, small size, and light weight. Internally, a programmable signal source is used, which can output single-phase, two-phase, or three-phase standard sine wave signals or high-frequency signals. The output phase frequency can be adjusted arbitrarily. The three-phase transformer ratio can be measured without adjusting the balance of the three-phase power supply, and the measurement accuracy can be guaranteed. Therefore, the testing speed is fast, and the transformer ratio and wiring method can be measured in about 3 seconds.

1. It can automatically measure the transformer ratio of three-phase and single-phase, and calculate the ratio error.

2. The number and polarity of transformer connection group can be measured.  And display a secondary wiring vector diagram, intuitive, the instrument has self-calibration function, according to the results of self-calibration can distinguish test line or instrument failure.

3. Can display transformer voltage waveform diagram and phase relationship of the first and second, can measure transformer voltage harmonics harmonics, convenient analysis of transformer fault.

4. CT, PT ratio, polarity test function.

5. Perfect and reliable automatic protection function to ensure the instrument intact in all kinds of abnormal conditions.

6. The instrument has 128M built-in memory (extensible 4G memory card), which can store all the measurement results. The database can be exported by usb disk, and the database can be opened by Excel spreadsheet.

7. 7 inch true color touch screen operation, emWinGUI interface, simple and convenient operation.
