| AC current output |
| Phase current output (effective value) | 0~40A, Output Precision 0.2 degree |
| 3 phase parallel current output (effective value) | 0~120A |
| A Long-time Phase current | 10A |
| Maximum output power of Phase current | 450VA |
| Maximum output power of 3 parallel current | 900VA |
| Maximum Permitted work time of 3 parallel current | 10S |
| Frequency range ( fundamental) | 0~1000Hz |
| Harmonic time | 0~20 |
| DC current output |
| Current output | 0～±10A / phase, 0～±30A / 3 parallel |
| Output Precision | 0.5 degree |
| AC voltage output |
| Phase voltage output (effective value) | 0~120V Output Precision 0.2 degree |
| Line voltage output (effective value) | 0~240V |
| Phase voltage / Line phase output power | 80VA / 100VA |
| Frequency range (fundamental) | 0~1000Hz |
| Harmonic time | 0~20 |
| DC voltage output |
| Phase voltage output range | 0～±160V Output Precision 0.5 degree |
| Line voltage output range | 0～±320V |
| Phase voltage / Line phase output power | 70VA / 140VA |
| 10 path digital input and 8 path digital output |
| Time measuring range | 0.1ms ～ 9999s ，accuracy of measurement ＜0.1ms |
| Volume & weight | 400×360×160mm³ ，15kg |
