Booster output current & voltage |
1A/2500V
2A/1500V
5A/600V
10A/220V
20A/30V |
|
Current generator output current |
600A |
|
Output power |
3000VA |
|
Voltage and current measurement accuracy |
±0.2% |
CT ratio tests
Voltage method / current method |
Range |
1~40000 |
|
|
Accuracy |
±0.2% |
|
PT ratio tests |
Range |
1~40000 |
|
|
Accuracy |
±0.2% |
|
Phase measurement |
Accuracy |
±5min |
|
|
Resolving power |
0.5min |
|
Secondary winding resistance tests |
Range |
0~1kΩ |
|
|
Accuracy |
0.5%±2mΩ |
|
AC load tests |
Range |
0~1000VA |
|
|
Accuracy |
0.5%±0.05VA |
|
Power supply |
AC220V±10%，50Hz |
|
work environment |
Temperature: -10οC~50οC,Humidity: ≤90% |
|
Size & Weight |
Size: 425 mm×290 mm×310mm Weight: 30kg |
